1.2500" Diameter 12J1X-1201780R01 HiPos+ 12mm End Mill
This vendor requires us to bring the item into our Florida warehouse for the following states: AL,AZ,CO,DC,HI,ID,LA,ME,MD,MA,MS,MO,NM,NY,SC,VA,PR,AK,CT,OR before shipping to you.
3024886
3024886
12J1X-1201780R01
12J1X-1201780R01
Weight: 0.002 LBS
Brand: INGERSOLL CUTTING TOOLS
Product Description
12J1x-1201780R01 Hipos+ 12Mm End Mill Iso Item #12J1x-1201780R01 Ingersoll Part #3024886 Dc - Cutting Diameter : 1.250. Apmx - Depth Of Cut Max.: 0.490. Oal - Overall Length: 4.00. Zeff - Eff. Teeth: 4. Dcon - Shank Diameter : 1.0000. Csp - Coolant: Yes. Rmpx - Ramp Angle Max.: 3.5. Kapr - Cutting Edge Angle: 90.0. Lux - Usable Length Max.: 1.75. Lpr - Protruding Length: 1.75. Dc - Cutting Dia.: 1.250. Apmx - Depth Of Cut Max.: 0.490. Oal - Overall Length: 4.00. Zeff - Eff. Teeth: 4. Dcon - Shank Dia.: 1.0000. Csp - Coolant: Yes. Rmpx - Ramp Angle Max.: 3.5. Kapr - Cutting Edge Angle: 90.0. Lux - Usable Length Max.: 1.75. Lpr - Protruding Length: 1.75.
- 0.750-1.500" (Weldon)
- .49" Depth of cut
- 12mm Insert with 2 indexes
- 32-63 Ra surface finishes when engaging the integrated wiper (WEP)
- Insert corners: .015" .031", .062" .093" .125", .156 R
- 0.750-1.500" (Weldon)
- .49" Depth of cut
- 12 mm Insert with 2 indexes
- 32-63 Ra surface finishes when engaging the integrated wiper (WEP)
- Insert corners: .031", .062" .125" R
Shipping & Delivery Options
Illinois
Suncoast Shipping Deals
| Min. order amount |
Shipping Option |
Special Rate |
Max Weight |
|
$50.00
|
UPS Blue 2 Business Days |
$19.99 |
5 LBS |
| Note: Special vendor shipping deals are destination-based and may not be available in all ZIP codes. If this rate is not available for your shipping address, standard shipping options will be shown at checkout. |
$50.00 MINIMUM ORDER
If ordered by 4pm Eastern Standard Time items will be ordered and shipped to our Florida location from Ingesoll. Once received, we will ship from our warehouse and provide you with the tracking number. We can drop-ship directly to Florida customers.
Additional Product Details
Technical Details
- Manufacturer
- INGERSOLL CUTTING TOOLS
- Manufacturer Part Number
- 3024886
- Cutter Diameter
- 1.2500"
- Overall Length
- 4"
-
Coolant Through
- Yes
