Din6987150sem32x100c Rotary Tooling Lf - Functional Length: 100.00 Mm. Bd - Body Diameter : 66.00 Mm. Lb - Body Length: 80.90 Mm. Lsc - Clamping Length: 24.00 Mm. Ccms - Connection Code Machine Side: Din69871-50. Dcon - Pilot Diameter : 32.00 Mm. Cnsc - Coolant Entry Style Code: 1. Cxsc - Coolant Exit Style Code: 1. Dcp - Data Chip Provision: No.

• DIN69871 Form ADB
• Shell Mill Holder with Internal Coolant Holes ISO 3937 (Metric)
• ADB Style Coolant with Ported Coolant Delivery
• Symmetrical Design
• Dynamically balanced for high RPM machining
• DIN69871-40 Balanced G2.5 @ 20,000 RPM
• DIN69871-50 Balanced G2.5 @ 15,000 RPM
