ER20SRK3/16X2.500 Rotary Tooling ShrinkIn

This vendor requires us to bring the item into our Florida warehouse for the following states: AL,AZ,CO,DC,HI,ID,LA,ME,MD,MA,MS,MO,NM,NY,SC,VA,PR,AK,CT,OR before shipping to you.
ER20SRK3/16X2.500 Rotary Tooling ShrinkIn ER20SRK3/16X2.500 Rotary Tooling ShrinkIn ER20SRK3/16X2.500 Rotary Tooling ShrinkIn ER20SRK3/16X2.500 Rotary Tooling ShrinkIn
INGERSOLL CUTTING TOOLS
4540636
4540636
ER20SRK3/16X2.500
ER20SRK3/16X2.500
Weight: 0.227 LBS
Brand: INGERSOLL CUTTING TOOLS
$145.00
(8% off)
$133.54
each
Add To My Favorites
Technical Details & Downloads
Technical/Extra Information
Product Description

Er20srk3/16X2.500 Rotary Tooling Shrinkin Iso Item #Er20srk3/16X2.500 Ingersoll Part #4540636 Dcon - Bore Diameter : 0.188. Bd - Body Diameter : 0.394. Lb - Body Length: 0.970. Bhta - Body Half Taper Angle: 4.0. Ccms - Connection Code Machine Side: Er20. Cnsc - Coolant Entry Style Code: 1. Cxsc - Coolant Exit Style Code: 1. Lbx - Body Length Max.: 2.500. Lscn - Clamping Length Min.: 0.590. Lscx - Clamping Length Max.: 0.830. Bdx - Body Diameter Max.: 0.530.

  • ER Series Integral Collet
  • Thermal Shrink Adaption
  • 1450 Max PSI
  • For use with Carbide Shank Tooling only
  • *See Notes below
