Hskfm80sem3/4X2.00 Rotary Tooling Iso Item #Hskfm80sem3/4X2.00 Ingersoll Part #4592751 Lf - Functional Length: 2.000. Bd - Body Diameter : 1.772. Lb - Body Length: 0.976. Lsc - Clamping Length: 0.669. Ccms - Connection Code Machine Side: Hsk F80/Fm80. Dcon - Pilot Diameter : 0.750. Cnsc - Coolant Entry Style Code: 1. Cxsc - Coolant Exit Style Code: 1. Dcp - Data Chip Provision: No. Df - Flange Diameter : 3.150.

• HSK-FM (DIN 69893/F)
• Shell Mill Holder ISO 3937
• For use on Makino models MAG Series A machines
• Balanced G2.5@33,000 RPM
• Note: Orientation pins can be removed for use as a standard HSK F spindle adaption
