3" Diameter 7 Flute TPKT16 Insert Indexable Coolant-Thru 90° Shoulder Face Mill Milling Cutter, 1" Bore, 2.189" Connection Diameter, 1.75" Overall Length

3" Diameter 7 Flute TPKT16 Insert Indexable Coolant-Thru 90° Shoulder Face Mill Milling Cutter, 1" Bore, 2.189" Connection Diameter, 1.75" Overall Length
YG-1 TOOL CO.
17000963
17000963
17000963
F90-TP16-D300Z7S100I
Weight: 3.648 LBS
Brand: YG-1 TOOL CO.
$681.09
(8% off)
$626.94
each
Add To My Favorites
Technical Details & Downloads
Technical/Extra Information
Product Description

3" Diameter 7 Flute Tpkt16 Insert Indexable Coolant-Thru 90° Shoulder Face Mill Milling Cutter, 1" Bore, 2.189" Connection Diameter, 1.75" Overall Length

  • YG-1 SM3 MILL: True 90° Shoulder TPKT Indexable Face Mill
  • 90° Shoulder Face Mill Style Cutters With Coolant Holes Through The Body
  • Utilizes economical positive TPKT inserts with 3 cutting edges for cutting true 90° shoulders
  • Enlarged core diameter provides for higher rigidity
  • The new TPKT inserts with 3 cutting edges have:
  • High positive rake face for optimized chip formation & minimized burr formation
  • Curved cutting edge to minimize mismatch while step machining
  • High helix cutting edge for smooth cutting & lowered cutting force
  • Wiper flat cutting edge provides for an excellent surface finish

This item is part of our complete offering of YG-1 Cutting Tools, trusted for high-performance CNC machining, consistent quality, and broad application coverage across milling, drilling, threading, tool holding, and indexable operations. Browse YG-1 End Mills for carbide and cobalt milling solutions, YG-1 Hole Making Tools for drills and reamers, YG-1 Threading Tools for taps and thread mills, YG-1 Tool Holders for dependable tool holding solutions, and YG-1 Indexable Tooling for productive insert-based machining. You can also visit our main YG-1 Cutting Tools page to shop the full line and compare sizes, coatings, and performance styles for your application.

Made in Korea, Republic of
Shipping & Delivery Options
VERNON HILLS, ILLINOIS, USA
  • UPS

Suncoast Shipping Deals

Min. order amount Shipping Option Special Rate Max Weight
$399.00 UPS Ground 1 – 4 Business days (Lower 48 States) $0.00 10 LBS
$25.00 UPS Ground 1 – 4 Business days (Lower 48 States) $8.99 15 LBS
$499.00 UPS Blue 2 Business Days $9.99 7 LBS
$399.00 UPS Blue 2 Business Days $13.99 5 LBS
$50.00 UPS Blue 2 Business Days $15.99 6 LBS
Note: Special vendor shipping deals are destination-based and may not be available in all ZIP codes. If this rate is not available for your shipping address, standard shipping options will be shown at checkout.
$25.00 MINIMUM ORDER
If Ordered By 3pm Eastern Standard Time YG Will Ship Same Business Day
Factory Stock
70
Add to Cart

Additional Product Details

Technical Details

Manufacturer
YG-1 TOOL CO.
Manufacturer Part Number
17000963
Cutter Diameter
3.000" 3"
Thread Size
N/A
Shank Diameter
N/A
Number Of Flutes
7
Primary Application
90° Shoulder Milling
Angle Per Side
90° Lead Angle
Hand Cutting Direction
Right Hand Cutting
Uses Insert
TPKT16
Inch Or Metric
Inch
Country of Origin
Korea, Republic of
Type
Face Mill
Shank Type
N/A
Hole Size
1"
Coolant Through
With Coolant Holes
