5/8" 6 Flute .090" Corner Radius Carbide End Mill, 1-5/8" LOC, 5/8" Plain Shank, 41° Helix, T-Carb Series 51CR, Ti-NAMITE-X (TX) Coated, For HP High Speed Machining

5/8" 6 Flute .090" Corner Radius Carbide End Mill, 1-5/8" LOC, 5/8" Plain Shank, 41° Helix, T-Carb Series 51CR, Ti-NAMITE-X (TX) Coated, For HP High Speed Machining 5/8" 6 Flute .090" Corner Radius Carbide End Mill, 1-5/8" LOC, 5/8" Plain Shank, 41° Helix, T-Carb Series 51CR, Ti-NAMITE-X (TX) Coated, For HP High Speed Machining
KYOCERA SGS PRECISION TOOLS
SGS35119
35119
51C06250_090TX
UPC: 691781351193
Weight: 0.535 LBS
Brand: KYOCERA SGS PRECISION TOOLS
$366.74
(47% off)
$195.58
each
Add To My Favorites
Technical Details & Downloads
Speeds & Feeds Catalog Page Catalog Page
Product Description

Sgs T-Carb 6-Flute Series 51 - The T-Carb 6-Flute High Performance End Mills Are Ideal For Aggressive High Speed Machining Using Trochoidal And Peel Milling Techniques. The Additional Flutes Allow Higher Feed Rates At Reduced Tool Loads, Ultimately Preventing Breakage And Failure. The Variable Pitch Geometry Allows The T-Carb To Excel In Multiple Operations Calling For Aggressive Roughing And Finishing, Resulting In Faster Cycle Times And Lower Costs. Designed For Aggressive Ramping At High Speeds Where Evacuation And Load Might Be A Factor. Engineered For High Speed Milling Using Trochoidal And Peel Milling Techniques. Exceptional Performance With Minimal Deflection In Difficult Materials Such As Titanium Alloys And Stainless Steels. Eccentric Relief Provides Superior Strength And Smoother Surface Finish. Variable Flute Geometry Maximizes Productivity And Tool Life By Reducing The Harmful Harmonics Associated With Aggressive Milling. The Series Is Offered In A Variety Of Length, Neck And End Configuration Options And Is Coated With Ti-Namite-X For Ultimate Thermal Barrier Protection. Ti-Namite-X Provides Outstanding Results In A Diverse Range Of Applications Including Medium-Hard To Very Hard Steels (40–65 Hrc) And Titanium Alloys. The Layered Design Of The Coating, Along With The Nanocomposite Grain Structure Provides The Hardness Necessary For Extreme Wear Resistance With The Toughness Required To Withstand Interrupted Cutting. Ti-Namite-X Allows For A Broad Spectrum Of High-Performance Machining From Aggressive Material Removal Rates To High Speed Machining And Finishing.

  • Engineered for High Speed Milling using Trochoidal and Peel Milling techniques
  • Eccentric relief provides superior strength and smoother surface finish
  • Enhanced corner geometry with tight tolerance corner radii
  • Recommended for materials <= 45 HRc (<= 420 Bhn)
Made in U.S.A.
Shipping & Delivery Options
CUYAHOGA FALLS, OHIO USA
  • UPS
$50.00 MINIMUM ORDER
SGS-Kyocera will Ship Same Business Day if ordered by 1pm Eastern Standard Time
Factory
0
Currently Unavailable Notify Me
Please sign in or register to be notified when this product is back in stock.

Additional Product Details

Technical Details

Manufacturer
KYOCERA SGS PRECISION TOOLS
Manufacturer Part Number
35119
Cutter Diameter
0.6250" 5/8"
Length Of Cut
1.6250"
Overall Length
2.5000"
Shank Diameter
0.6250"
Radius Size
.090"
Number Of Flutes
6
Helix Angle
41°
End Style
Corner Radius
Tool Coating
TX (Ti-NAMITE-X)
Tool Substrate Material
Carbide
Primary Application
HP High Speed Machining
Hand Cutting Direction
Right Hand Cutting
Material Food Group
(P), (M), (K), (S), Also (H)
Inch Or Metric
Inch
Country of Origin
U.S.A.
Hand Helix Direction
Right Hand Helix
Series
51CR
Single Or Double End
Single End
Center Cutting
Yes
Flute End Type
Center Cutting
Type Of End Mill
Finisher
Model
T-Carb
Shank Type
Plain Shank
Neck Diameter
Does not apply
Chip Breaker
No
Coolant Through
No Coolant Holes
Length
Regular
Helix Type
Regular Helix
