4.10mm 2 Flute Stub Length (3XD) Solid Carbide Drill, 145° Point, Straight Shank, 22mm Flute, 55mm OAL, AlTiN (Ti-NAMITE-A) Coated, Series 108 For General Application, SGS Part #68689
4.10mm 2 Flute Stub Length (3XD) Solid Carbide Drill, 145° Point, Straight Shank, 22mm Flute, 55mm OAL, AlTiN (Ti-NAMITE-A) Coated, Series 108 For General Application, SGS Part #68689
SGS68689
68689
108D01614DNTA
UPC: 691781686899
Weight: 0.025 LBS
Brand: KYOCERA SGS PRECISION TOOLS
$84.81
(49% off)
$42.83
each
Factory
0
Additional Product Details
Technical Details
- Manufacturer
- KYOCERA SGS PRECISION TOOLS
- Manufacturer Part Number
- 68689
- Length Of Flute
- 0.8661" 22mm
- Overall Length
- 2.1654" 55mm
- Shank Diameter
- Equals Drill Diameter
- Number Of Flutes
- 2
- Drill Point Angle
- 145°
- Drill Type
- Stub Length Drill
- Helix Angle
- 27°
- Tool Coating
- AlTiN (Ti-NAMITE-A)
- Tool Substrate Material
- Carbide
- Hand Cutting Direction
- Right Hand Cutting
- Material Food Group
- (P), (M), (K), (N), (S), Also (H)
- Inch Or Metric
- Metric
- Country of Origin
- U.S.A.
- Hand Helix Direction
- Right Hand Helix
- Series
- 108
- Shank Type
- Straight Shank
- Drill Diameter
- 0.1614" 4.10mm
- Reach Multiple
- 3xD
- Coolant Through
- No Coolant Holes
- Depth Of Cut
- 0.6693" 17.00mm
- Helix Type
- Right Hand Spiral
